Through beam photoelectric sensors

  • Infrared light source can be customized.

  • Operating voltage: 24-240VAC,12-240VDC, 10-30VDC

  • Output function: NPN/PNP,light-ON,dark-ON.

  • Protection level: IP67

  • With polarity, overload, short circuit protection.

  • Wiring method:lead wire type、connector type.

  • Operating temperature:-25℃...+55℃

  • P5050 series with transistor output and relay output.

  • With the advantages of small size, multi-function, long service life, high precision, fast response speed, long detection distance and strong anti-light, electric and magnetic interference ability.

Data download
Diameter Mounting Operating distance/Sn Housing material Operating voltage Output model Connection type
M18*79 Through beam 15m PBT 24-240VAC Emitter:AC ​2 Wire; Receiver:AC 4 Wire HLT-P18 M12 Connector
M18*67 Through beam 15m PBT 24-240VAC Emitter:AC ​2 Wire; Receiver:AC 4 Wire HLT-P18 PVC, 2 m
M18*79 Through beam 15m Nickel plated brass 24-240VAC Emitter:AC ​2 Wire; Receiver:AC 4 Wire HLT-C18 M12 Connector
M18*67 Through beam 15m Nickel plated brass 24-240VAC Emitter:AC ​2 Wire; Receiver:AC 4 Wire HLT-C18 PVC, 2 m
M18*79 Through beam 15m PBT 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-P18 M12 Connector
M18*67 Through beam 15m PBT 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-P18 PVC, 2 m
M18*79 Through beam 15m Nickel plated brass 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-C18 M12 Connector
M18*67 Through beam 15m Nickel plated brass 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-C18 PVC, 2 m
M12*76.5 Through beam 10m PBT 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT2-P12 M12 Connector
M12*67 Through beam 10m PBT 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT2-P12 PVC, 2 m
M12*76.5 Through beam 5.2m PBT 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-P12 M12 Connector
M12*67 Through beam 5.2m PBT 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-P12 PVC, 2 m
M12*76.5 Through beam 10m Nickel plated brass 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT2-C12 M12 Connector
M12*76.5 Through beam 10m Nickel plated brass 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-C12 M12 Connector
M12*67 Through beam 10m Nickel plated brass 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT2-C12 PVC, 2 m
M12*67 Through beam 5.2m Nickel plated brass 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-C12 PVC, 2 m
M8*71.5 Through beam 3000.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT5-C08 M8 Connector
M8*71.5 Through beam 1000.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT4-C08 M8 Connector
M8*71.5 Through beam 500.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT3-C08 M8 Connector
M8*71.5 Through beam 150.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT2-C08 M8 Connector
M8*71.5 Through beam 80.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-C08 M8 Connector
M8*62.5 Through beam 3000.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT5-C08 PVC, 2 m
M8*62.5 Through beam 1000.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT4-C08 PVC, 2 m
M8*62.5 Through beam 500.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT3-C08 PVC, 2 m
M8*62.5 Through beam 150.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT2-C08 PVC, 2 m
M8*62.5 Through beam 80.0mm Nickel plated brass/stainless steel 10-30VDC Emitter:DC ​2 Wire; Receiver:DC 4 Wire HLT-C08 PVC, 2 m
