Current position：Home - Products - Ordinary inductive sensors - AC/DC inductive proximity switch

Operating voltage: 20-250VAC/VDC;
Output function: NPN/PNP, NO/NC optional
Protection class: IP67
Direct outlet type, connector type
Operating temperature-25℃-+70℃
Optimized traditional process and advanced packaging technology to ensure long-term stable operation in harsh environments

Data download

Diameter	Mounting	Operating distance/Sn	Housing material	Operating voltage	Output	Model	Connection type
M12	flush/non-flush	2mm/4mm/6mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M12*1	straight line
M12	flush/non-flush	2mm/4mm/6mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M12*1	connector
M18	flush/non-flush	5mm/8mm/12mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M18*1	straight line
M18	flush/non-flush	5mm/8mm/12mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M18*1	straight line
M18	flush/non-flush	5mm/8mm/12mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M18*1	connector
M18	flush/non-flush	5mm/8mm/12mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M18*1	connector
M30	flush/non-flush	10mm/15mm/22mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M30*1	straight line
M30	flush/non-flush	10mm/15mm/22mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M30*1	straight line
M30	flush/non-flush	10mm/15mm/22mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M30*1	connector
M30	flush/non-flush	10mm/15mm/22mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	M30*1	connector
RS40	flush/non-flush	15mm/30mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	R40*40	connector
R40	flush/non-flush	15mm/30mm	Nickel plated copper/stainless steel	20-250VAC/VDC	AC/DC 2 wire	R40*40	connector
R40	flush/non-flush	15mm/30mm	Nickel plated copper/stainless steel	20-250VAC	AC/DC 2 wire	R40*40	connector
